Главная Каталог товаров KTM EPC 2006 KTM Offroad KTM 2006 Enduro KTM 2006 Offroad 200 EXC (7203F0) [EU] KTM (VIN: VBKGSA20) CARBURETOR

CARBURETOR

CARBURETOR

Например: 52331001444

1

52331001444

CARBURETOR KEIHIN PWK 38AG 06

2

54631245000

STARTER PISTON CPL.

3

54631209000

FLOAT R-39 16GRAM

4

54631211000

FLOAT CHAMBER

5

54531610000

Gasket - float chamber

6

54531699000

PLUG M 18X1

7

0770180230

O-RING 18,00X2,30 NBR 70

8

54631220000

FLOAT NEEDLE

9

54531612100

RETAINING PLATE FOR BLEEDER

10

54531607035

IDLE JET 35 KEIHIN

10

54531607040

IDLE JET 40 KEIHIN

10

54531607042

IDLE JET 42 KEIHIN

10

54531607045

IDLE JET 45 KEIHIN

10

54531607048

IDLE JET 48 KEIHIN

10

54531607050

IDLE JET 50 KEIHIN

11

54531636004

JET NEEDLE NOZ D KEIHIN

11

54531636005

JET NEEDLE NOZ E KEIHIN

11

54531636006

JET NEEDLE NOZ F KEIHIN

11

54531636007

JET NEEDLE NOZ G KEIHIN

11

54531636008

JET NEEDLE NOZ H KEIHIN

11

54531636009

JET NEEDLE NOZ I KEIHIN

11

54531634175

JET NEEDLE R 1475 J KEIHIN

11

54531634272

JET NEEDLE R 1472 N KEIHIN

11

54731034200

JET NEEDLE KEIHIN R1468G 03

11

54731034300

JET NEEDLE KEIHIN R1469G 03

12

54531629000

CLIP FOR JET NEEDLE

13

54631235006

THROTTLE VALVE 60 KEIHIN

13

54631235106

THROTTLE VALVE 65 KEIHIN

13

54631235055

THROTTLE VALVE 55 KEIHIN

14

54631232000

NIPPLE

15

54631227000

CARBURETOR COVER

16

54531628000

RUBBER SEAL RING 40X46X1

17

54531617000

ADJUSTMENT SCREW

18

54531615000

SPRING FOR ADJUSTMENT SCREW

19

54831030000

SLIDING SPRING

20

54531621000

Collier

21

0016040133

Vis

22

31007007101

PVC-HOSE 4X6MM

23

52031137001

PVC-HOSE 3X5MM

24

57331008000

ARM PIN FLOAT

25

54531696000

CLAMP 6 MM

26

54531623168

MAIN JET 168 KEIHIN

26

54531623165

MAIN JET 165 KEIHIN

26

54531623170

MAIN JET 170 KEIHIN

26

54531623172

MAIN JET 172 KEIHIN

26

54531623175

MAIN JET 175 KEIHIN

26

54531623178

MAIN JET 178 KEIHIN

26

54531623180

MAIN JET 180 KEIHIN

27

54831029000

THROTTLE CALBE HOLDER M6X0,75

29

54631219100

ADJUSTMENT SCREW M 5

30

54631118000

Spring

31

54631231000

SPRING CAP

33

50331029036

SLIDE STOP L=36MM

34

0770060018

O-RING 6,07X1,78 FPM75
