Airbox

Airbox

Например: T2206510

1

T2206510

Airbox Assy, LHS

2

T2206511

Inner Moulding, Airbox, LHS

3

T2206514

Outer Moulding, Airbox, LHS

4

T2206512

Duct, Intake, Throttle, LHS

5

T2206513

Duct, Intake, Airbox

2 шт. в узле

6

T2206530

Air Filter, LHS

7

T2206532

Joint boîte de filtre

2 шт. в узле

8

T3331414

Screw, S/Tap, Torx, 5 x 16

9

T2206517

Gasket, Airbox, LHS

10

T2206536

Bracket, Fusebox

11

T2206538

Bracket, Main Fuse

12

T3332464

Screw, S/Tap, THF, 5 x 25

2 шт. в узле

13

T2206520

Airbox Assy, RHS

14

T2206521

Inner Moulding, Airbox, RHS

15

T2206524

Outer Moulding, Airbox, RHS

16

T2206522

Duct, Intake, Throttle, RHS

17

T2206531

Air Filter, RHS

2 шт. в узле

18

T2206518

Gasket, Airbox, RHS

19

T2206534

Bracket, Airbox, RHS

20

T2206535

Bracket, Airbox, LHS

21

T3331043

Screw, Pan/Hd, Tx, M6 x 12, Sl

4 шт. в узле

22

T3205254

Bolt, HHF, Lghtd, M8 x20, Slv

3 шт. в узле

23

T3010077

Flanged Sleeve, M8 x 11.2 x 2.

2 шт. в узле

24

T2206519

Duct, Adjustment, Throttle

2 шт. в узле

25

T3700041

Clip, Intake, Venturi, 60mm, C

4 шт. в узле

26

T3020054

Grommet, Sidepanel

2 шт. в узле

27

T2306127

Finisher, Intake, LH, Brushed

28

T2306128

Finisher, Intake, RH, Brushed

29

T2206515

Mount, Intake Finisher, LH

30

T2206516

Mount, Intake Finisher, RH

31

T2201540

Bracket, Finisher Mount

32

T3332656

Screw, Button, M5 x 0.8 x 12,

8 шт. в узле

33

T3350161

Nut, Captive, M5

34

T3020131

Grommet, 9 x 2 x 6

4 шт. в узле

35

T2206539

Hose, Breather, Crankcase

36

T2206508

Hose, Breather, LH

37

T2206507

Hose, Breather, RH

38

T2206505

Breather, Inline, Moulding

39

T2206506

Cap, Breather, Inline, Mouldin

40

T3700050

Hose Clip, Dia 19.5-22.0 x 8mm

2 шт. в узле

41

T3700076

Hose Clip, 14-15.5

4 шт. в узле

42

T3601470

O Ring, ID 32.5 x 3

43

T2206544

Foam, Breather, Inline
