Главная Каталог товаров Triumph EPC 2016 Triumph THRUXTON R Triumph 2016 (VIN: SMTDAD72) Airbox

Airbox

Airbox

Например: T2201106

1

T2201106

Airbox Assy, D44 Throttles

2

T2201122

Air Filter

3

T2201058

Seal, Filter Face

4

T2201129

Casette, Air Filter

5

T2200937

Mount Plate, Filter Cassette

6

T3330319

Screw, S/Tap, 5 x 20

4 шт. в узле

7

T2202173

Intake Duct, LH, D44 Throttle

8

T2201073

Intake Duct, RH, D44 Throttle

9

T2200939

Grommet, Insertion, Intake Duc

10

T2102242

Hose Clip, 23-25, Bright, Ss

11

T2201488

Foam, Breather Chamber, In-Lin

12

T2201457

Moulding, Breather, In-Line

13

T2201497

Cap, Breather Chamber, In-Line

14

T2201124

Hose, Crankcase Breather

15

T3700050

Hose Clip, Dia 19.5-22.0 x 8mm

16

T2201434

Drain Tube, Sealed

17

T3700081

Clip hose

18

T2306127

Finisher, Intake, LH, Brushed

19

T2306128

Finisher, Intake, RH, Brushed

20

T2306129

Mount, Intake Finisher, LH

21

T2306130

Mount, Intake Finisher, RH

22

T3020131

Grommet, 9 x 2 x 6

4 шт. в узле

23

T3332656

Screw, Button, M5 x 0.8 x 12,

8 шт. в узле

24

T3350129

Nut, Captive, M5

2 шт. в узле

25

T3010031

Flanged Sleeve, M6

4 шт. в узле

26

T3330334

Screw, Tx, Pan/HD, M6 x 16, Sl

27

T2201134

Intake Duct, HP Airbox

28

T3700041

Clip, Intake, Venturi, 60mm, C

2 шт. в узле

29

T2201540

Bracket, Finisher Mount

30

T3350161

Nut, Captive, M5

2 шт. в узле

31

T3331260

Screw, Thread Forming, 5 x 20

32

T3660176

Rubber Strip

2 шт. в узле
