AIR FILTER|Frame|06

AIR FILTER|Frame|06
Например: 26606001000AB
1
26606001000AB
Lower section of the air filter
2
25106004000ABF
ir filter box cover right
3
25106003000ABF
ir filter box cover left
5
47106003160
quick release rubber grommet
7
83008000012
Vis (spec)
8
59001092050
Vis (spec)
9
79006015000
Filtre à air
10
79006016000
AIR FILTER SUPPORT
11
79006017000
FILTER MOUNTING BRACKET
12
79406226133
Intake connection boot cmpl.
13
51006027000
HOSE CLAMP 50-70MM
14
0017060206
SCREW F. PLASTIC K60X20AL SW6
15
77304066050
chain slider bushing
16
79006010010
SPLASH PROTECTOR KIT
17
25105090000
HEAT PROTECTION SUBFRAME
18
25105090044
HEAT PROTECTOR SET
19
0081050141
EJOT PT screw K50x14
22
25106014000AB
Side fairing
23
25106013000AB
Side fairing
24
79105098000
exhaust spacer
