9 - CARBURETOR (MODEL R/S/T)

9 - CARBURETOR (MODEL R/S/T)
Например: 13200-44AE1
0
13200-44AE1
Carburettor
1
13502-42A00
COVER,DIAPHRAGM
1 975 ₽/шт
2
13417-42A00
Пружина
595 ₽/шт
3
13382-42A00
RING
187 ₽/шт
4
13394-40D20
E RING
282 ₽/шт
5
13387-47010
RING
323 ₽/шт
6
09494-00825
Jet,needle(p-5)
7
02112-0408B
Болт
940 ₽/шт
8
13556-05A11
Seal,throttle Shaft
238 ₽/шт
9
13617-44080
E RING
231 ₽/шт
10
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
11
13578-47070
CAP
364 ₽/шт
12
13500-42A01
Diaphragm assy
13
13602-43410
Болт
172 ₽/шт
14
13411-42A20
PLUNGER ASSY
3 655 ₽/шт
15
13295-29901
O-Ring, Pilot Air Screw
210 ₽/шт
16
13291-29900
Шайба
162 ₽/шт
17
13268-47070
Пружина
272 ₽/шт
18
13279-47070
Винт топливный
884 ₽/шт
19
09492-40014
Жиклерпроводник
731 ₽/шт
20
13382-03110
Шайба
178 ₽/шт
21
09491-22016
JET,MAIN(110)
1 148 ₽/шт
22
13383-42A00
Жиклер
1 207 ₽/шт
23
13250-42A00
Поплавок
2 190 ₽/шт
24
13254-92311
PIN,FLOAT
162 ₽/шт
25
13370-44500
Запорная игла поплавковой камеры
3 655 ₽/шт
26
13251-42A00
Прокладка поплавковой камеры
629 ₽/шт
27
13374-35C00
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
275 ₽/шт
28
13376-19F00
Фильтр-сеточка
581 ₽/шт
29
09493-28005
Jet,air
30
02112-0412A
Болт
85 ₽/шт
31
13268-37420
Пружина
289 ₽/шт
32
13267-25D00
Регулятор
708 ₽/шт
33
13573-42A10
.spring
34
13574-45120
Ring
35
13684-40A00
HOSE(3X5X650)
731 ₽/шт
36
09352-50005-600
ШЛАНГ
436 ₽/шт
37
13247-02340
Заглушка дренажная
258 ₽/шт
