5 - CRANKCASE

5 - CRANKCASE

Например: 11310-03820

1

11310-03820

Crankcase set,r

2

09319-12060

Втулка

12 000 ₽/шт

3

11320-03830

CRANKCASE SET. LH

4

09319-12060

Втулка

12 000 ₽/шт

5

09319-10032

Втулка

580 ₽/шт

6

01550-0885A

БОЛТ

2 070 ₽/шт

7

01550-0865A

БОЛТ

153 ₽/шт

8

01547-0635A

БОЛТ

97 ₽/шт

9

01547-0655A

БОЛТ

1 410 ₽/шт

10

04211-11169

PIN

113 ₽/шт

11

11323-03H00

PLATE,GEAR BOX

594 ₽/шт

12

01547-0612A

БОЛТ

81 ₽/шт

13

09247-14026

Пробка редуктора сливная

289 ₽/шт

14

09168-14004

Прокладка

129 ₽/шт

15

01550-0812B

Болт

97 ₽/шт

16

09168-08016

Прокладка

129 ₽/шт

17

01550-0812B

Болт

97 ₽/шт

18

09103-12058

BOLT(12X215)

8 800 ₽/шт

19

08310-0012A

Гайка

81 ₽/шт

20

09247-12006

Заглушка масляной магистрали

1 640 ₽/шт

21

09168-12021

GASKET(12X16.5X2.2)

980 ₽/шт

22

11390-21F00

Жиклер

1 748 ₽/шт

23

09280-04004

O RING(D:1.2,ID:4.0)

194 ₽/шт

24

09106-06075

БОЛТ

1 450 ₽/шт

25

11431-12J00

COVER,GEAR BOX

14 154 ₽/шт

26

01550-0830A

БОЛТ

119 ₽/шт

27

04211-11169

PIN

113 ₽/шт

28

11484-12J00

GASKET,GEAR BOX COVER

880 ₽/шт

29

11186-49F00

SEPARATOR,OIL BREATHER

1 904 ₽/шт
