47 - FRAME COVER (UH125ZL3 P19)

47 - FRAME COVER (UH125ZL3 P19)

Например: 47111-03H00-YC3

1

47111-03H00-YC3

over, frame uh

1

47111-03H00-YBD

Cover, frame rh (white)

2

47211-03H00-NE2

Cover frame,lh

2

47211-03H00-YBD

Cover frame,lh

3

68131-07E10

mblem'burgman'

4

68155-07E10

MBLEM R

5

68135-07E00

TAPE. FRAME COVER LOWER RH

5

68135-07E10

TAPE. FRAME UH125/L3

6

68145-07E00

TAPE. FRAME COVER LOWER LH

6

68145-07E10

Tape, frame cover lower lh

7

68155-07E00

TAPE. FRAME COVER UPPER RH

7

68155-07E40

TAPE. FRAME UH125/L3

8

68165-07E00

TAPE. FRAME COVER UPPER LH

8

68165-07E40-RAC

Tape, frame cover upper lh

9

09409-08308-5ES

CLIP(GRAY)

178 ₽/шт

10

03541-0516B

Болт

81 ₽/шт

11

47351-03H00-Y0J

Cover, frame uh

12

47311-03H00-NE2

Cover, center

12

47311-03H00-YBD

Cover, center (white)

13

44281-C29C0-0

ushion

14

D91BL-4815A

Nut

15

09689-24603

Винт

83 ₽/шт

16

47411-03H00-YC3

over, frame uh

16

47411-03H00-YBD

Cover, rear lower (white)

17

09409-08326

КЛИПСА КАНСОЛИ ЦЕНТРАЛЬНОЙ, ПЛАСТИК

81 ₽/шт

18

68131-03HA0-YJH

Emblem uh125&20

19

47161-03H00

Cushion,front u

20

47162-03H00

Cushion,front u
