42 - FRONT DAMPER (MODEL D/E/F/G)

42 - FRONT DAMPER (MODEL D/E/F/G)

Например: 51103-13600-14C

1

51103-13600-14C

Damper assy, rh (red)

1

51103-13600-14L

Damper assy, rh (white)

1

51103-13600-163

Damper assy, rh (yellow)

2

51104-13600-14C

Damper assy, lh (red)

2

51104-13600-14L

Damper assy, lh (white)

2

51104-13600-163

Damper assy, lh (yellow)

3

51130-13600-14C

.outer tube, rh (red)

3

51130-13600-14L

.outer tube, rh (white)

3

51130-13600-163

.outer tube, rh (yellow)

4

51140-13600-14C

.outer tube, lh (red)

4

51140-13600-14L

.outer tube, lh (white)

4

51140-13600-163

.outer tube, lh (yellow)

5

51147-48130

BOLT(8X27)

221 ₽/шт

6

51148-36011

GASKET

210 ₽/шт

7

51183-31030

Прокладка

210 ₽/шт

8

09100-06157

BOLT(6X8)

102 ₽/шт

9

51195-48000

PIECE,OIL LOCK

1 581 ₽/шт

10

51177-48720

.spring, rebound

11

51146-13600

.cylinder

12

51196-48000

Кольцо

459 ₽/шт

13

51168-20900

SPACER SEAL

14

51153-48420

Сальник

1 148 ₽/шт

15

51156-48730

SEAL,OIL STOPPER RING

238 ₽/шт

16

51173-20400

SEAL,DUST

1 683 ₽/шт

17

51110-13600

FR FORK INNER TUBE

18

51171-13600

Пружина

1 939 ₽/шт

19

51181-33131

O RING

364 ₽/шт

20

51175-48500

SEAT,SPRING

633 ₽/шт

21

51169-48500

Кольцо

172 ₽/шт

22

51189-26515

FR FORK CAP

23

51452-46040

CLIP,FR BRAKE CABLE

340 ₽/шт

24

08321-0104A

Пластина замка

82 ₽/шт

25

02112-0420A

Болт

85 ₽/шт
