41D - COWLING BODY (MODEL P)

41D - COWLING BODY (MODEL P)

Например: 94401-21C70-1LE

1

94401-21C70-1LE

over assy, cowling rh (blue)

1

94401-21C70-33J

over assy, cowling rh (black)

2

68680-20C50-A4A

.tape set, rh

2

68680-20C50-A3Y

.tape set, rh

3

68681-20C10-A4A

.emblem, katana

3

68681-20C10-A4B

.emblem, katana

4

94433-19C01

over,meter sid

4

94433-19C01-33J

over,meter r.s

5

03541-0410A

Болт

85 ₽/шт

6

94631-49310

MOLD,COWLING

8 835 ₽/шт

7

94635-19C00

MOLDING

918 ₽/шт

8

94438-19C00

Joint

9

94435-19C01-1LE

.lid, oil (blue)

9

94435-19C01-33J

LID,OIL

2 463 ₽/шт

10

09139-06030

Винт (6X16)

194 ₽/шт

11

94402-21C70-1LE

over assy, cowling lh (blue)

11

94402-21C70-33J

over assy, cowling lh (black)

12

68690-20C50-A4A

Tape set,cowl,l

12

68690-20C50-A3Y

LH TAPE SET

13

68681-20C10-A4A

.emblem, katana

13

68681-20C10-A4B

.emblem, katana

14

94443-19C01-1LE

.cover, meter side lh (red)

14

94443-19C01-33J

over,meter l.s

15

03541-0410A

Болт

85 ₽/шт

16

94631-49310

MOLD,COWLING

8 835 ₽/шт

17

94635-19C00

MOLDING

918 ₽/шт

18

94438-19C00

Joint

19

94420-20C02

over cmp,meter

20

94635-20C00

MOLDING,METER COVER

21

94421-19C01-1LE

NTER PANEL

21

94421-19C01-33J

PANEL,COWLING CTR

3 324 ₽/шт

22

94471-19C00-1LE

over,cwl.und.r

22

94471-19C00-33J

over under rh

23

94481-19C00-1LE

over,cwl.und.l

23

94481-19C00-33J

OVER,COWLING UNDER,L

17 243 ₽/шт

24

94475-19C01

over cowling

25

94573-20C00

Sheet,cowl.bal.

25

94583-20C00

SCHILD

26

94574-20C00

Sheet,cowl.bal.

26

94584-20C00

Sheet, cow balancer lh

27

94576-20C00

ushion

27

94586-20C00

RUBBER

28

94610-20C60

Screen,wind

29

94631-18D01

Molding,windscr

30

94915-44E00

CUSHION UNER COWL R

578 ₽/шт

31

68319-33E11

Ярлык предупреждающий

676 ₽/шт

32

68922-14F01

Label,screen

771 ₽/шт

32

68922-14F31

Label,screen

567 ₽/шт

33

68332-20C31

34

68341-20C00

Label, rear shock absorber
