41A - FRONT WHEEL (MODEL K2/K3/K4/K5 E06,E24)

41A - FRONT WHEEL (MODEL K2/K3/K4/K5 E06,E24)

Например: 54111-44A10

1

54111-44A10

HUB,FR WHEEL

18 260 ₽/шт

2

09180-12146

SPACER(12.5X19X60.5)

7 740 ₽/шт

3

08113-6201B

earing

1 024 ₽/шт

4

08133-62017

BEARING

1 139 ₽/шт

5

54711-44A01

XLE,FR

2 111 ₽/шт

6

54740-02B40

SPACER,FR AXLE

954 ₽/шт

7

54600-01A01

Box Assy,speedometer Gear

5 474 ₽/шт

8

59221-13A01

DISC,FR BRAKE

26 180 ₽/шт

9

09106-08155

BOLT(8X20)

2 390 ₽/шт

10

08322-0112B

Шайба

85 ₽/шт

11

08319-2112A

Гайка

211 ₽/шт

12

55110-44AF0

TIRE,FR(70/100-21 44M)

11 847 ₽/шт

13

55200-44AF0

Tube assy, wheel inner

14

55261-44AF0

PROTECTOR,WHL INR TUBE

348 ₽/шт

15

55311-08D10

RIM,FR WHEEL(21X1.60 FE)

20 016 ₽/шт

16

55320-44A01

Комплект спиц, переднего колеса

5 929 ₽/шт
