37A - FRONT WHEEL (AE50RP/RR/RS/RT/RV)

37A - FRONT WHEEL (AE50RP/RR/RS/RT/RV)
Например: 54140-29C40-37W
1
54140-29C40-37W
heel, front (2.15x10)(red)
2
54731-29C11
Spacer, wheel bearing
3
54732-29C00
Support, bearing spacer
4
09262-10013
Bearing (10x30x9)
5
09285-16005
Seal,oil(16X30X8)
954 ₽/шт
6
54711-16B00
EIXO FRENTE
7
54741-16B00
SPACER,FR AXLE,R
446 ₽/шт
8
08319-31107
Гайка
210 ₽/шт
9
55100-29C20
Tire, front 80/90-10 (irc)
10
55220-29C20
Valve assy, wheel rim (pvr-65)
11
54210-29C00-37W
Panel, front brake cnchor (red)
12
09160-05001-A05
Шайба,5.1X9X0.4
119 ₽/шт
13
54621-16B00
Pinion,speedome
14
54632-02201
BUSH,SPEEDOMETER PINION OUTER
884 ₽/шт
15
54217-16B00
COVER.FR BK AHR PNL BOSS
16
54611-16B01
GEAR,SPEEDOMETER(NT:23)
2 295 ₽/шт
17
54225-16B00
Spacer, anchor panel boss
18
09285-34002
SEAL,OIL(34X42X5)
274 ₽/шт
19
54400-39820
SHOE SET,BRAKE
2 717 ₽/шт
20
09443-07025
Пружина
1 170 ₽/шт
21
54441-16B01
EXCENTRICO
22
09280-12012
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
391 ₽/шт
23
54484-16B00
Spring, lever return
24
09160-12011
Уплотнение
97 ₽/шт
25
54451-29C00
LEVER,FR BRAKE CAM
1 091 ₽/шт
26
01550-0625A
Болт
102 ₽/шт
27
08310-00067
Гайка
81 ₽/шт
28
54310-16B00
TORQUELINK COMP.FRONT
29
54341-25E00
BUSH,TORQUELINK
255 ₽/шт
30
54342-16B00
COVER,TORQUELINK
31
09100-08280
BOLT(8X49)
1 880 ₽/шт
32
08319-2108A
Гайка
1 250 ₽/шт
33
09100-08223
BOLT(8X35)
8 600 ₽/шт
34
08319-31087
Гайка
178 ₽/шт
