25 - SPEEDOMETER - TACHOMETER (GSX550ESD/ESE/EFE)

25 - SPEEDOMETER - TACHOMETER (GSX550ESD/ESE/EFE)
Например: 34120-43450
1
34120-43450
Speedometer (mile/kilo)
2
34220-43402
Tachometer
3
34320-43410
Fuelmeter
4
34150-43410
Hood,meter
5
34112-43410
Glass
6
34153-43410
Plate, window
7
34111-43400
Case, meter
8
36300-43810
Lens set, pilot
9
09132-03501
Болт
1 330 ₽/шт
10
34131-43400
Gear box
11
02112-04107
Болт
82 ₽/шт
12
08321-0104A
Пластина замка
82 ₽/шт
13
02112-0310A
Болт
1 060 ₽/шт
14
09162-03001
Шайба блокирующая
900 ₽/шт
15
08322-01037
Шайба
1 090 ₽/шт
16
02112-0306B
Болт
940 ₽/шт
17
08322-01037
Шайба
1 090 ₽/шт
18
34170-43400
Socker
19
09471-12028
Лампочка
210 ₽/шт
20
09471-12077
BULB(12V1.7W,T10,WB121)
1 990 ₽/шт
21
36453-43410
Socket, gear indicator
22
09471-12071
BULB(14V1.12W)
3 440 ₽/шт
23
34182-43400
Plate
24
03212-04103
Vis
25
34950-43410
Bracket, meter
26
34995-45720
Cushion, no.1
27
34996-43410
ВТУЛКА УПЛОТНИТЕЛЬНАЯ
170 ₽/шт
28
09160-05037
Шайба
97 ₽/шт
29
08310-00057
Гайка
81 ₽/шт
30
08321-0104A
Пластина замка
82 ₽/шт
31
09160-04024
Шайба
1 290 ₽/шт
32
08310-00047
Гайка
81 ₽/шт
33
34193-43400
Cover, lower
34
03111-0412A
Болт
1 060 ₽/шт
35
34956-31001
CUSHION,METER BRACKET
501 ₽/шт
36
09160-08135
Шайба
113 ₽/шт
37
08321-0108B
Пластина замка
81 ₽/шт
38
08310-0008B
Гайка
85 ₽/шт
39
34910-38430
CABLE ASSY,SPEEDOMETER
3 050 ₽/шт
40
34938-45100
CLAMP,SPEEDOMETER CABLE
254 ₽/шт
41
01107-06168
Vis
42
08322-0106A
Шайба
81 ₽/шт
