22B - FRONT DAMPER (MODEL M)

22B - FRONT DAMPER (MODEL M)

Например: 51103-28C71

0

51103-28C71

Damper assy, rh

0

51104-28C71

Damper assy, lh

1

51110-27C40

.tube, inner rh

2

51120-27C41

3

51121-27C40

Bush ,slide

4

51171-28C70

.spring, main

5

51146-27C40

.cylinder

6

51175-03B30

O RING

301 ₽/шт

7

51170-28C70

.bolt, center

8

51148-27C40

Прокладка

399 ₽/шт

9

51189-08D00

CAP

618 ₽/шт

10

51175-27C40

Spacer,spring

11

51176-27C40

Ring,piston

12

51190-28C61

13

51355-27C41

Seat,spr.stop.

14

51130-27C40

.tube, outer

15

51135-27C40

.case, oil seal

16

51131-27C40

O RING,CASE

563 ₽/шт

17

51134-27C40

.screw

18

51167-27C40

Bush ,guide

19

51133-27C40

.ring, stopper upper

20

51158-27C40

Кольцо/шайба

489 ₽/шт

21

51153-28E30

Сальник

2 268 ₽/шт

22

51156-27C40

RING,OIL SEAL STOPPER

204 ₽/шт

23

51173-28E40

Пыльник

2 581 ₽/шт

24

51180-27C40

.adjuster, spring

25

09280-12012

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

391 ₽/шт

26

51351-27C40

BOLT,FORK

7 976 ₽/шт

27

51117-27C40

Кольцо уплотнительное

328 ₽/шт

28

51357-27C40

BOLT,PLUG

528 ₽/шт

29

51117-19C10

Кольцо уплотнительное

210 ₽/шт

30

51132-27C40

ase,oil seal

31

08319-31067

Гайка

153 ₽/шт

32

59248-27C40

Guide,hose lh

33

01500-05087

Болт

1 210 ₽/шт

34

51501-05D60

PROTECTOR,FORK,R

34

51511-27C40

PROTECTOR,FORK,L

5 279 ₽/шт

35

58627-27C40

Болт

231 ₽/шт

36

51201-27C40

Guide,protector

36

51211-27C40

GELEIDER

37

58628-27C40

BOLT,PROTECTOR GUIDE

274 ₽/шт
