19 - CONTACT BREAKER

19 - CONTACT BREAKER
Например: 33110-45020
1
33110-45020
Breaker assy, contact
2
33140-44110
Point assy,cont
3
33160-44110
Point assy,cont
4
33143-45020
.plate, contact point shifting
5
02112-0406B
Болт
81 ₽/шт
6
08322-01047
Шайба
85 ₽/шт
7
08321-0104A
Пластина замка
82 ₽/шт
8
33261-45020
Condenser
9
02112-0406B
Болт
81 ₽/шт
10
08321-0104A
Пластина замка
82 ₽/шт
11
33120-45021
Governor assy, advance
12
33371-45001
Plate,ignition
13
01500-0865B
БОЛТ
2 030 ₽/шт
14
33465-47000
WASHER
1 544 ₽/шт
15
09125-05024
SCREW(5X12)
1 250 ₽/шт
16
09160-05028
Шайба
940 ₽/шт
17
09404-06039
Clamp(L:65)
194 ₽/шт
18
09404-08420
Струбцина L:137
221 ₽/шт
19
09407-18501
Clamp
