14 - CLUTCH

14 - CLUTCH
Например: 21200-45101
1
21200-45101
Gear, primary driven (nt:87)
2
09160-25056
WASHER
727 ₽/шт
3
21251-49200
Entretoise
4
09263-51002
BEARING(51X56X28)
3 675 ₽/шт
5
21411-45100
Hub, sleeve
6
21471-45101
SEAT,WAVE WASHER
1 161 ₽/шт
7
21481-45100
RING,WAVE WASHER STOPPER
238 ₽/шт
8
09164-00003
ШАЙБА ФОРСУНКИ
646 ₽/шт
9
09140-24007
ШАЙБА
2 390 ₽/шт
10
09167-25007
ШАЙБА
1 560 ₽/шт
11
09160-25022
WASHER(25X66X3.5)
10 710 ₽/шт
12
21441-45100
PLATE,CLUTCH DRIVE
2 072 ₽/шт
13
21451-31000
PLATE,CLUTCH DRIVEN(T:2.0)
974 ₽/шт
14
21462-12C00
DISC,CLUTCH PRESSURE
4 888 ₽/шт
15
09440-19027
Пружина
211 ₽/шт
16
01550-0616B
БОЛТ
81 ₽/шт
17
09160-06066
Шайба
102 ₽/шт
18
16321-49000
Шестерня масленого насоса
14 991 ₽/шт
19
16325-45001
SPACER,OIL PUMP DRIVE GEAR
1 449 ₽/шт
20
09263-36002
Roulement
21
23165-45111
Rack, release
22
09263-15003
Подшипник 15X28X2
532 ₽/шт
23
09160-15045
Шайба
211 ₽/шт
24
09285-10003
Oil seal
25
23261-49001
Pinion, release
26
09285-12006
САЛЬНИК ТРАНСМИССИИ, РЕЗИНА
275 ₽/шт
27
09263-15012
BEARING(15X22X12)
1 052 ₽/шт
28
23271-45400
Arm,clutch rele
29
01550-06207
БОЛТ
85 ₽/шт
