13 - TRANSMISSION (3)

13 - TRANSMISSION (3)
Например: 24140-07900
1
24140-07900
Axle shaft, rear (nt:71)
2
24381-07930
Gear, idler driven (nt:37)
3
09263-15003
Подшипник 15X28X2
532 ₽/шт
4
09160-15034
Thrust washer no.2 (t:1.0)
5
09160-15035
Thrust washer no.1 (t:2.0)
6
24220-07901
Gear, 2nd drive (nt:46)
7
21502-02121
ND CLUTCH ASSY
8
21220-07901
Housing assy, clutch
9
09263-15027
Bearing
10
09380-32002
КЛИПС
2 540 ₽/шт
11
22521-02101
Guide, 2nd clutch assy
12
09263-35010
Thrust bearing
13
22531-02100
Retainer
14
24231-07900
Gear, 3rd drive (nt:55)
15
09180-15064
Spacer
16
09263-24015
Bearing
17
09160-15034
Thrust washer
18
09263-15003
Подшипник 15X28X2
532 ₽/шт
19
09160-12051
WASHER(12X27X2)
1 210 ₽/шт
20
09140-12023
Nut
21
21411-07900
Hub, 3rd clutch sleeve
22
06111-15004
BALL
1 170 ₽/шт
23
22541-07900
Spacer, 3rd clutch sleeve hub
24
21481-07901
Spring, clutch return
25
09160-30032
Thrust washer, sleeve hub
26
09263-30014
Roulement
27
09160-30030
Thrust washer
28
21441-25C01
PLATE,CLUTCH DRIVE
2 261 ₽/шт
29
21442-02100
Plate, drive (t:2.5)
30
21451-36200
PLATE
697 ₽/шт
30
21451-01B40
Диск сцепления стальной (T:1.4)
991 ₽/шт
30
21451-19A00
Диск сцепления
901 ₽/шт
31
21471-02100
Dumper, clutch plate
32
24871-02101
Plate, oil reserver
33
02122-05088
Screw
34
09283-27010
САЛЬНИК
937 ₽/шт
35
08130-62047
BEARING
2 014 ₽/шт
36
24751-07900
RETAINER,DRIVE SHAHFT BEARING
227 ₽/шт
37
02112-3616A
Болт
1 210 ₽/шт
37
02112-0616A
Болт
81 ₽/шт
