13 - CARBURETOR (MODEL K3)

13 - CARBURETOR (MODEL K3)

Например: 13201-01DH0

1

13201-01DH0

Carburettor (LH)

1

13201-01DJ0

Carburettor (LH)

2

13202-01DH0

Carburettor (RH)

2

13202-01DJ0

Carburettor (RH)

3

13573-19E00

Пружина

867 ₽/шт

4

13418-33E00

HOLDER

337 ₽/шт

5

09280-05004

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

204 ₽/шт

6

13481-13F00

Пружина

187 ₽/шт

7

13382-19E00

Шайба

170 ₽/шт

8

13387-13F00

RING

425 ₽/шт

9

13383-01DH0

Жиклер

1 357 ₽/шт

10

13502-07F00

Крышка диафрагмы

3 441 ₽/шт

11

13501-29FA0

Клапан поршня

4 653 ₽/шт

12

13507-17C02

Diaphragm

3 460 ₽/шт

13

13247-02340

Заглушка дренажная

258 ₽/шт

14

09492-17016

JET,PILOT(17.5)

989 ₽/шт

15

02112-04107

Болт

82 ₽/шт

16

13258-44B00

Прокладка крышки поплавковой камеры

767 ₽/шт

17

13250-04F00

Поплавок

4 039 ₽/шт

18

13254-01010

PIN,FLOAT

162 ₽/шт

19

02112-0408B

Болт

940 ₽/шт

20

13602-05A10

Болт

238 ₽/шт

21

13370-33E81

Valve Assy,needle(Ni)

7 761 ₽/шт

22

09491-25018

JET,MAIN(127.5)

1 581 ₽/шт

23

09491-60010

JET,MAIN(60)

989 ₽/шт

24

13385-07F00

HOLDER,JET

1 951 ₽/шт

25

13246-43011

O Ring

194 ₽/шт

26

09494-00949

Жиклер игольчатый

3 597 ₽/шт

27

13279-33E00

Винт топливный

636 ₽/шт

28

13268-47070

Пружина

272 ₽/шт

29

13291-29900

Шайба

162 ₽/шт

30

13295-29901

O-Ring, Pilot Air Screw

210 ₽/шт

31

13267-13F00

SCREW,ADJUST

845 ₽/шт

32

13271-33C00

Пружина

238 ₽/шт

33

13411-05300

PLUNGER

2 635 ₽/шт

34

13682-31210

CAP,STARTER VALVE

459 ₽/шт

35

13418-44080

Держатель

867 ₽/шт

36

13417-26D00

Пружина

238 ₽/шт

37

13278-47091

O Ring

210 ₽/шт

38

13247-33E00

Болт

170 ₽/шт

39

09493-32007

JET,AIR(160)

931 ₽/шт

40

13274-84000

CAP

204 ₽/шт

41

09401-06101

CLIP

114 ₽/шт

42

13295-33010

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

194 ₽/шт

42

13281-05A00

PLUG

170 ₽/шт

43

13268-96111

Пружина

179 ₽/шт

44

13271-44B00

Пружина

238 ₽/шт

45

13267-44B00

Болт

238 ₽/шт

46

13683-01DF0

Hose

47

13413-01DE0

Plate

48

13602-04F00

Болт

239 ₽/шт

49

13557-33E00

PACKING

170 ₽/шт

50

13683-01DE0

Hose

51

13683-01DB0

HOSE

1 003 ₽/шт

52

13673-44B00

Сальник

291 ₽/шт

53

13685-33EQ0

Золотник

2 681 ₽/шт

54

13565-01DE0

Bracket

55

02122-0510A

Болт

85 ₽/шт

56

13685-01DB0

PIPE

751 ₽/шт

57

13684-48B11

Hose

1 771 ₽/шт

58

13685-48B00

NIPPLE

918 ₽/шт

59

09401-10401

CLIP

900 ₽/шт

60

13684-48B11

Hose

1 771 ₽/шт
