12 - TRANSMISSION (MODEL F)

12 - TRANSMISSION (MODEL F)
Например: 24121-14511
1
24121-14511
Countershaft (nt:14)
2
24221-14510
Gear,2nd drive (nt:16)
3
24231-14510
Gear,3/4 drive (nt:18/20)
4
24250-14510
Gear,5th drive (nt:21)
5
24261-14510
Gear,6th drive (nt:22)
6
09380-20007
КЛИПС
194 ₽/шт
7
09380-20012
Seeger
8
24131-14510
Shaft,drive
9
24311-14511
Gear,1st driven (nt:30)
10
24321-14510
Gear,2nd driven (nt:28)
11
24331-14510
Gear,3rd driven (nt:26)
12
24341-14510
Gear,4th driven (nt:25)
13
24351-14510
Gear,5th driven (nt:23)
14
24361-14510
Gear,6th driven (nt:22)
15
09181-15195
Шайба
1 520 ₽/шт
16
09380-22006
КЛИПС
194 ₽/шт
17
09167-22011
Пластина замка
1 880 ₽/шт
18
09262-20121
Подшипник
2 581 ₽/шт
19
08113-60020
ПОДШИПНИК ВЫЖИМНОЙ
1 208 ₽/шт
20
08123-6202B
Wheel bearing
21
09262-20043
Ball bearing 20
22
09283-25035
SEAL,OIL(25X40X7)
760 ₽/шт
23
24741-48000
RETAINER,CNTR SHAFT BEARING
352 ₽/шт
24
02112-06127
Болт
81 ₽/шт
24
02122-06127
Болт
85 ₽/шт
25
24751-14102
Holder,bearing
26
02122-06127
Болт
85 ₽/шт
27
26260-14100
TANDWIEL,START
28
09181-15166
SHIM(15X24X1)
179 ₽/шт
29
08331-3115A
CIRCLIP
97 ₽/шт
30
27511-14111
ШКИВ ПРИВОДНОЙ
2 385 ₽/шт
30
27511-14121
SPROCKET. ENGINE
3 460 ₽/шт
30
27511-14101
SPROCKET,ENGINE
3 558 ₽/шт
31
09180-20039
SPACER(20X25X12.5)
4 930 ₽/шт
32
09380-20007
КЛИПС
194 ₽/шт
33
09280-20001
O RING(D:1,ID:19.5)
179 ₽/шт
34
27600-43D02-116
CHAIN,DRIVE (DID520DMA4 SDH)
20 485 ₽/шт
35
27620-10221
Joint (rk)
35
27620-28C01
36
09180-12108
Spacer
