10 - TRANSMISSION (1)

10 - TRANSMISSION (1)
Например: 21110-41D00
1
21110-41D00
FACE,FIXED DRIVE
9 095 ₽/шт
2
21120-04C04
FACE,MOVABLE DRIVE
10 674 ₽/шт
3
09284-22003
SEAL,OIL(22X28X4)
602 ₽/шт
4
21431-41D00
PLATE,MOVABLE DRIVE
864 ₽/шт
5
21481-41D01
AMPER,MOVABLE DRIVE PLATE
383 ₽/шт
6
21650-41D12
Ролик ведущего вариатора
970 ₽/шт
7
21122-37B01
Крышка
387 ₽/шт
8
09280-85003
O RING
4 420 ₽/шт
9
02142-0410A
Винт
81 ₽/шт
10
09180-16044
SPACER(16X22X38.9)
20 330 ₽/шт
11
27601-04C03
V BELT,DRIVE
6 021 ₽/шт
12
26280-41D01
GEAR,KICK STARTER DRIVEN(NT:10
24 242 ₽/шт
13
26282-41D01
NUT,KICK STARTER
39 491 ₽/шт
14
09440-33003
Пружина
2 230 ₽/шт
15
26283-41D02
Держатель пружины
2 465 ₽/шт
16
26284-41D00
WASHER,KICK DRIVEN
1 169 ₽/шт
17
02112-7410B
SCREW
1 330 ₽/шт
