003 - SHIFT CAM - FORK » FRONT SUSPENSION

003 - SHIFT CAM - FORK » FRONT SUSPENSION
1
025147050
.THRUST WASHER 25.2X32.5X1
1
025147054
pc - . THRUST WASHER 25.2X32.5X1.2
1
85211081AH
.THRUST WASHER 25.2X32.5X0.9
1
85211081AL
.THRUST WASHER 25.2X32.5X1.1
1
85211081AN
.THRUST WASHER 25.2X32.5X1.3
2
15020061B
MAIN SHAFT
3
067016150
.THRUST WASHER 0.5 MM
4
70140051A
Needle bearing
5
17210043A
GEAR, INPUT 5TH, 24T
6
85610011A
.THRUST WASHER 0.5 MM
7
067016145
.SPRING RING
8
17210033A
GEAR DRIVE 3/4TH SPEED T20/22
9
17210053A
GEAR, 6TH DRIVE NT:28
10
17210021B
GEAR, 2ND DRIVE, NT:17
11
067016163
.THRUST WASHER 20.3X32X1.8
11
067016164
.THRUST WASHER 20.3X32X2
11
71310141A
.THRUST WASHER 20.3X32X1.5
11
71310141B
.THRUST WASHER 20.3X32X1.7
11
71310141E
THRUST WASHER 20.3X32X1.6
11
71310141F
THRUST WASHER 20.3X32X1.9
12
44910272A
.SPROCKET T15
13
82610111A
Plate, drive sprocket fixing
14
77210551A
pc - Vis (M5x0.8x16)
15
067016164
.THRUST WASHER 20.3X32X2
15
067016165
.THRUST WASHER 20.3X32X2.2
15
71312661A
THRUST WASHER 17.3X31X3.15
15
067016185
Rondelle (17.2x32x1.2)
15
71310111A
Rondelle (17.2x32x2.3)
15
71310141A
.THRUST WASHER 20.3X32X1.5
15
71310141E
THRUST WASHER 20.3X32X1.6
16
15020352A
COMPLETE LAY SHAFT
17
764020002
Needle bearing
18
17210061B
DRIVEN GEAR 1ST SPEED T37
19
067016150
.THRUST WASHER 0.5 MM
20
17210103A
DRIVEN GEAR 5TH SPEED 23T
21
17210092A
DRIVEN GEAR 4TH SPEED T:24
22
17210081A
DRIVEN GEAR 3RD SPEED T27
23
17210113A
DRIVEN GEAR 6TH SPEEDT:24
24
17212192A
DRIVEN GEAR 2ND SPEED T30
25
14910241A
DRIVEN SHAFT
26
067016170
.THRUST WASHER 0.8 MM
26
067016171
.THRUST WASHER 1.0 MM
26
85211051AB
.THRUST WASHER 0.9 MM
26
85211051AD
. THRUST WASHER 1.1 MM
26
85211051AG
.THRUST WASHER 0.7 MM
27
15020052A
COMPLETE MAIN SHAFT
28
93040491A
Joint
29
70250441A
pc - Needle bearing
30
85610311A
.THRUST WASHER 0.5 MM

Узлы для Superbike 996 DUCATI 2001 (VIN: ZDM1SB5T)
